Solar charge controllers

A charge controller, charge regulator or battery regulator limits the rate at which electric current is added to or drawn from electric batteries. It prevents overcharging and may prevent against overvoltage, which can reduce battery performance or lifespan, and may pose a safety risk. It may also prevent completely draining ("deep discharging") a battery, or perform controlled discharges, depending on the battery technology, to protect battery life. The terms "charge controller" or "charge regulator" may refer to either a stand-alone device, or to control circuitry integrated within a battery pack, battery-powered device, or battery recharger.

In solar applications, charge controllers may also be called solar regulators. Some charge controllers / solar regulators have additional features, such as a low voltage disconnect, a separate circuit which powers down the load when the batteries become overly discharged (some battery chemistries are such that over-discharge can ruin the battery).

A series charge controller or series regulator disables further current flow into batteries when they are full. A shunt charge controller or shunt regulator diverts excess electricity to an auxiliary or "shunt" load, such as an electric water heater, when batteries are full.

Simple charge controllers stop charging a battery when they exceed a set high voltage level, and re-enable charging when battery voltage drops back below that level. Pulse width modulation (PWM) and maximum power point tracker (MPPT) technologies are more electronically sophisticated, adjusting charging rates depending on the battery's level, to allow charging closer to its maximum capacity.

Charge controllers may also monitor battery temperature to prevent overheating. Some charge controller systems also display data, transmit data to remote displays, and data logging to track electric flow over time.

Plants: image 2 0f 4 thumb

SPECIFICATION  OF SOLAR CHARGE CONTROLLER
Sr No Model D2D Function DC Volts Max.
Charging
Current(I/P)
Max.Load
Current(O/P)
Max. Solar Photovoltaic panels Dimention
(L x W x H )mm
1 Solar CC 12V
4A/8A
With Out D2D 12 V Upto 04 Amps Upto 08 Amps 48 W 165 X 110 X 65
2 Solar CC 12/24V  10A/10A With Out D2D 12V-24V Upto 10 Amps Upto 10 Amps 120W  in 12V
240W in 24V
165 X 110 X 65
3 Solar CC 12/24V  10A/10A With  D2D 12V-24V Upto 10 Amps Upto 10 Amps 120W  in 12V
240W in 24V
165 X 110 X 65
4 Solar CC 12/24V  15A/15A With Out D2D 12V-24V Upto 15 Amps Upto 15 Amps 180W  in 12V
360W in 24V
165 X 110 X 65
5 Solar CC 12/24V  15A/15A With  D2D 12V-24V Upto 15 Amps Upto 15 Amps 180W  in 12V
360W in 24V
165 X 110 X 65
6 Solar CC 12/24V 20A/20A With Out D2D 12V-24V Upto 20 Amps Upto 20 Amps 240W  in 12V
480W in 24V
165 X 110 X 65
7 Solar CC 12/24V 20A/20A With  D2D 12V-24V Upto 20 Amps Upto 20 Amps 240W  in 12V
480W in 24V
165 X 110 X 65
8 Solar CC 12/24V 40A/40A With & With out D2D 12V-24V Upto 40 Amps Upto 40 Amps 480W  in 12V
960W in 24V
165 X 110 X 65
9 Solar CC 24/48V 40A/40A With & With out D2D 24V-48V Upto 40 Amps Upto 40 Amps 960W  in 24V
1920W in 48V
165 X 110 X 65
10 Solar CC MPPT
24V-50A
With Out D2D 24V Upto 50 Amps Upto 50 Amps 1700W in 24V 250 X 300 X 400
11 Solar CC MPPT
24V-75A
With Out D2D 24V Upto 75 Amps Upto 75 Amps 2550W in 24V 250 X 300 X 400
12 Solar CC MPPT
24V-100A
With Out D2D 24V Upto 100 Amps Upto 100 Amps 3400W in 24V 250 X 300 X 400
13 Solar CC MPPT
48V-50A
With Out D2D 48V Upto 50 Amps Upto 50 Amps 3400W in 48V 250 X 300 X 400
14 Solar CC MPPT
48V-75A
With Out D2D 48V Upto 75 Amps Upto 75 Amps 5100W in 48V 250 X 300 X 400
15 Solar CC MPPT
48V-100A
With Out D2D 48V Upto 100 Amps Upto 100 Amps 6800W in 48V 250 X 300 X 400
16 Solar CC MPPT
96V-75A
With Out D2D 96V Upto 75 Amps Upto 75 Amps 10200W in 96V 250 X 300 X 400
17 Solar CC MPPT
192V-10A
With Out D2D 192V Upto 10 Amps Upto 10 Amps 2720W in 192V 250 X 300 X 400

 technichal Click Here For More Technical Specifications
